| Varenummer | B070ATN02.0 |
| Mærke | AUO |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 600×1024 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | AUO |
| panel model | B070ATN02.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 600(RGB)×1024 , WSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 89.28×152.37 mm |
| omrids | 96.98×163.82×4.25 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S6PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 32 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
