| Varenummer | N101BCG-GK1 |
| Mærke | Innolux |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | INNOLUX |
| panel model | N101BCG-GK1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 222.52×125.11 mm |
| omrids | 234.93×139.17×4.3 mm |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 14/11 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S6PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 39 pins |
| indgangsspænding | 3.3/1.2V (Typ.)(VDD/Core_VDD) |
| Ansøgning | PAD |
| CLAA101ND07CW | CPT | 10.1 | 1024×600 |
| CLAA101WB03 | CPT | 10.1 | 1366×768 |
| HSD101PFW3-D00 | HannStar | 10.1 | 1024×600 |
| LP101WH2-TLA2 | LG Display | 10.1 | 1366×768 |
| LP101WSA-TLB1 | LG Display | 10.1 | 1024×600 |
| M101NWT2 R3 | IVO | 10.1 | 1024×600 |
| N101BCG-GK1 | Innolux | 10.1 | 1366×768 |
| N101BCG-L21 | Innolux | 10.1 | 1366×768 |
| N101BGE-L21 | Innolux | 10.1 | 1366×768 |
| N101BGE-L31 | Innolux | 10.1 | 1366×768 |
| A070PAN01.0 | AUO | 7.0 | 900×1440 |
| B080XAN01.0 | AUO | 7.9 | 768×1024 |
| B101EVT04.0 | AUO | 10.1 | 1280×800 |
| BP082WX1-100 | BOE | 8.2 | 1280×800 |
| LD070WX6-SM01 | LG Display | 7.0 | 800×1280 |
| LT070ME05000 | JDI | 7.0 | 1200×1920 |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| Q070LRE-LB1 | Innolux | 7.0 | 1024×600 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| VVX07H005A90 | Panasonic | 7.0 | 800×1280 |
