| Varenummer | VVX07H005A90 |
| Mærke | Panasonic |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 800×1280 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1000:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | Panasonic |
| panel model | VVX07H005A90 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×1280 , WXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 94.2×150.72 mm |
| omrids | 104.32×161.67×3.8 mm |
| overflade | Hard coating |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 30 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S5PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 34 pins |
| indgangsspænding | 1.8/3.3V (Typ.)(VCC/VDD) |
| Ansøgning | PAD |
