| Varenummer | N140HGE-EA1 |
| Mærke | Innolux |
| Størrelse | 14.0 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | INNOLUX |
| panel model | N140HGE-EA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 309.14×173.89 mm |
| omrids | 320.4×187.1×3 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare (Haze 24%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 3/7 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP140WH2-TLM2 | LG Display | 14.0 | 1366×768 |
| LP140WHU-TPB2 | LG Display | 14.0 | 1366×768 |
| LTN140AT16-401 | Samsung | 14.0 | 1366×768 |
| LTN140AT20-W05 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-801 | Samsung | 14.0 | 1366×768 |
| LTN140KT04-201 | Samsung | 14.0 | 1600×900 |
| N140HCE-EBA | Innolux | 14.0 | 1920×1080 |
| N140HGE-EA1 | Innolux | 14.0 | 1920×1080 |
| N140HGE-EAA | Innolux | 14.0 | 1920×1080 |
| N140HGE-EBA | Innolux | 14.0 | 1920×1080 |
| B101EW01 V0 | AUO | 10.1 | 1280×720 |
| B121EW09 V3 HW0A | AUO | 12.1 | 1280×800 |
| B173RW01 V1 | AUO | 17.3 | 1600×900 |
| LP156WD1-TLD3 | LG Display | 15.6 | 1600×900 |
| LP156WH1-TLC2 | LG Display | 15.6 | 1366×768 |
| LQ141X1LH03 | SHARP | 14.1 | 1024×768 |
| LTN133W1-L01 | Samsung | 13.3 | 1280×800 |
| LTN156AT05-601 | Samsung | 15.6 | 1366×768 |
| LTN184KT01-F01 | Samsung | 18.4 | 1680×945 |
| NT116WHM-N11 | BOE | 11.6 | 1366×768 |
