| Varenummer | HN116WX1-100 |
| Mærke | BOE |
| Størrelse | 11.6 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | BOE |
| panel model | HN116WX1-100 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 11.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 256.125×144 mm |
| omrids | 268×169.5×5.2 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 30 (Max.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S4PWLEDWithout Driver |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| B116XTN01.0 HW5A | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW4A | AUO | 11.6 | 1366×768 |
| B116XW03 V0 | AUO | 11.6 | 1366×768 |
| HN116WX1-100 | BOE | 11.6 | 1366×768 |
| HN116WX1-203 | BOE | 11.6 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| N116HSE-EBC | Innolux | 11.6 | 1920×1080 |
| NT116WHM-N22 | BOE | 11.6 | 1366×768 |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| BT156GW01 V.3 | Innolux | 15.6 | 1366×768 |
| HV150UX2-100 | HYDIS | 15.0 | 1600×1200 |
| LP156WH4-TLB1 | LG Display | 15.6 | 1366×768 |
| LTN101AT03-801 | Samsung | 10.1 | 1366×768 |
| LTN133AT17-W01 | Samsung | 13.3 | 1366×768 |
| LTN140AT07-L01 | Samsung | 14.0 | 1366×768 |
| LTN190W1-L01 | Samsung | 19.0 | 1680×1050 |
| N156B6-L01 | Innolux | 15.6 | 1366×768 |
| N156B6-L0B | Innolux | 15.6 | 1366×768 |
