| Varenummer | NL3224AC35-01 |
| Mærke | NLT |
| Størrelse | 5.5 |
| Ansøgning | CNS |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 85:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | NEC |
| panel model | NL3224AC35-01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 111.36×83.52 mm |
| omrids | 134×110 mm |
| overflade | Antiglare |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 85:1 (Typ.) |
| vise farver | Full color , CIE193150% |
| responstid | 16/44 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/30/15 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog RGB, 30 pins |
| indgangsspænding | 9.5V (Typ.) |
| Ansøgning | CNS |
