| Varenummer | LS800JT9001 |
| Mærke | Innolux |
| Størrelse | 8.0 |
| Ansøgning | CNS |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | ChiHsin |
| panel model | LS800JT9001 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 162×121.5 mm |
| omrids | 183×141 mm |
| overflade | Antiglare (Haze 25%) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S9PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| indgangsspænding | 3.3/8.4/16/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | CNS |
| AT080TN42 V.1 | Innolux | 8.0 | 800×600 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| AV080WSM-NW0 | BOE | 8.0 | 1024×600 |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
| DLC0800AIG-2 | Other | 8.0 | 800×480 |
| HSD080IFW1-A00 | HannStar | 8.0 | 1024×600 |
| LA080WV2-TD01 | LG Display | 8.0 | 800×480 |
| LS800JT9001 | Innolux | 8.0 | 800×600 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| C070VW04 V5 | AUO | 7.0 | 800×480 |
| G150X1-L02 | Innolux | 15.0 | 1024×768 |
| HSD070IFW1-A00 | HannStar | 7.0 | 1024×600 |
| LA061WQ1-TD04 | LG Display | 6.1 | 480×272 |
| LA070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LQ049B5DG02 | SHARP | 4.9 | 320×96 |
| ND068-101A1 | 6.8 | 1280×480 | |
| PA050DS7N1 | E Ink | 5.0 | 320×234 |
| TM062RDH03 | Tianma | 6.2 | 800×480 |
