| Varenummer | NL4827HC19-01B |
| Mærke | NLT |
| Størrelse | 4.3 |
| Ansøgning | PND |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | NEC |
| panel model | NL4827HC19-01B |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 8/17 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/70/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 stringsWLEDWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 51 pins |
| indgangsspænding | 3.0/5.0/15.0/-15.0V (Typ.)(VCC/VDD/VGON/VGOFF) |
| Ansøgning | PND |
| 43WVF1G | SII | 4.3 | 800×480 |
| A043FW02 V8 | AUO | 4.3 | 480×272 |
| AT043TN25 V.1 | Innolux | 4.3 | 480×272 |
| CLAA048LA0BCW | CPT | 4.8 | 800×480 |
| LB043WQ2-TD08 | LG Display | 4.3 | 480×272 |
| LB050WQ3-TD04 | LG Display | 5.0 | 480×272 |
| LMS480KC01 | Samsung | 4.8 | 800×480 |
| LMS500HF04-002 | Samsung | 5.0 | 480×272 |
| LQ036T1DG01C | SHARP | 3.6 | 272×480 |
| TMT035DNAFWU19 | Tianma | 3.5 | 320×240 |
