| Varenummer | NL6448AC33-15 |
| Mærke | NLT |
| Størrelse | 10.4 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 150:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | NEC |
| panel model | NL6448AC33-15 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 211.2×158.4 mm |
| omrids | 251×196×24 mm |
| overflade | |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 150:1 (Typ.) |
| vise farver | Full color , CIE193155% |
| responstid | 40 (Max.)(Tr) |
| synsvinkel | 50/50/15/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog RGB, 23 pins |
| indgangsspænding | 5.0/12.0V (Typ.)(VCC/VDD1) |
| Ansøgning | IA |
