| Varenummer | LQ12X12 |
| Mærke | SHARP |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 150 |
| CR | 100:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ12X12 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 245.76×184.32 mm |
| omrids | 283×215.6×17 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 150 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Min.) |
| vise farver | 262K (6-bit) |
| responstid | 30/50 (Typ.)(Tr/Td) |
| synsvinkel | 35/35/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (2 ch, 6-bit), 50 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
| LQ101K5DZ01 | SHARP | 10.1 | 1280×422 |
| LQ104S1DG31 | SHARP | 10.4 | 800×600 |
| LQ104V1DG61 | SHARP | 10.4 | 640×480 |
| LQ104X2LX05B | SHARP | 10.4 | 1024×768 |
| LQ121S1LG45 | SHARP | 12.1 | 800×600 |
| LQ121X3LG02 | SHARP | 12.1 | 1024×768 |
| LQ140Z1JW01 | SHARP | 14.0 | 3200×1800 |
| LQ141X1LH03 | SHARP | 14.1 | 1024×768 |
| LQ150X1LGC2 | SHARP | 15.0 | 1024×768 |
| LQ164M1LD4C | SHARP | 16.4 | 1920×1080 |
| AA121XN01 | Mitsubishi | 12.1 | 1024×768 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| DLC1210BBG | Other | 12.1 | 800×600 |
| G084SN05 V5 | AUO | 8.4 | 800×600 |
| LJ32H028 | SHARP | 4.7 | 320×240 |
| LM12S472 | SHARP | 12.1 | 800×600 |
| LQ9D03B | SHARP | 8.4 | 640×480 |
| NL10276BC16-06 | NLT | 8.4 | 1024×768 |
| NL10276BC30-34D | NLT | 15.0 | 1024×768 |
| TX38D25VM0CAA | KOE | 14.9 | 1280×242 |
