| Varenummer | NL6448BC20-35D |
| Mærke | NLT |
| Størrelse | 6.5 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | NEC |
| panel model | NL6448BC20-35D |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.5 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 132.48×99.36 mm |
| omrids | 153×118 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193140% |
| responstid | 3/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3 stringsWLEDWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 31 pins |
| indgangsspænding | 3.3/5.0V (Typ.) |
| Ansøgning | IA |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
| NL6448BC20-08E | NLT | 6.5 | 640×480 |
| NL6448BC20-20 | NLT | 6.5 | 640×480 |
| NL6448BC20-30F | NLT | 6.5 | 640×480 |
| NL6448BC26-27 | NLT | 8.4 | 640×480 |
| NL6448BC33-21 | NLT | 10.4 | 640×480 |
| NL6448BC33-63D | NLT | 10.4 | 640×480 |
| NL6448BC33-64E | NLT | 10.4 | 640×480 |
| NL6448BC33-70D | NLT | 10.4 | 640×480 |
| AA050MG01 | Mitsubishi | 5.0 | 800×480 |
| B084SN02 V0 | AUO | 8.4 | 800×600 |
| DMF5005N-EB | Kyocera | 5.2 | 240×64 |
| KCS057QV1AJ-G23 | Kyocera | 5.7 | 320×240 |
| LM081HB1T01 | SHARP | 8.1 | 640×240 |
| LM64C21P | SHARP | 8.0 | 640×480 |
| LQ057Q3DG02 | SHARP | 5.7 | 320×240 |
| LTA057A340F | TOSHIBA | 5.7 | 320×240 |
| MD400F640PD5 | Panasonic | 9.8 | 640×400 |
| TX14D11VM1CAA | KOE | 5.7 | 320×240 |
