| Varenummer | NL8060BC31-02 |
| Mærke | NLT |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 90 |
| CR | 150:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | NEC |
| panel model | NL8060BC31-02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 246×184.5 mm |
| omrids | 275×199×8 mm |
| overflade | Antireflection |
| lysstyrke | 90 cd/m² (Typ.) |
| kontrastforhold | 150:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193142% |
| responstid | 40 (Typ.)(Tr) |
| synsvinkel | 50/50/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 41 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VCC) |
| Ansøgning | IA |
| NL8060AC26-04 | NLT | 10.4 | 800×600 |
| NL8060AC26-11 | NLT | 10.4 | 800×600 |
| NL8060BC21-02 | NLT | 8.4 | 800×600 |
| NL8060BC21-03 | NLT | 8.4 | 800×600 |
| NL8060BC26-13 | NLT | 10.4 | 800×600 |
| NL8060BC26-27 | NLT | 10.4 | 800×600 |
| NL8060BC26-30C | NLT | 10.4 | 800×600 |
| NL8060BC26-30D | NLT | 10.4 | 800×600 |
| NL8060BC31-17 | NLT | 12.1 | 800×600 |
| NL8060BC31-28D | NLT | 12.1 | 800×600 |
| AA070MC11 | Mitsubishi | 7.0 | 800×480 |
| DMF50081NB-FW | Kyocera | 4.7 | 320×240 |
| G121I1-L01 | Innolux | 12.1 | 1280×800 |
| G150XGE-L06 | Innolux | 15.0 | 1024×768 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| KG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| MD400F640PD5 | Panasonic | 9.8 | 640×400 |
| NL4823BC37-05 | NLT | 7.0 | 480×234 |
| PD080SL2 | E Ink | 8.0 | 800×600 |
| RGC11096096FR007 | RiTdisplay | 1.1 | 96×96 |
