| Varenummer | PP047JC-02A |
| Mærke | No Brand |
| Størrelse | 4.7 |
| Ansøgning | Mobile Phone |
| Løsning | 750×1334 |
| Sammensætning | LTPS TFT-LCD, CELL |
| Lysstyrke | |
| CR | 1500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No |
| Interface | |
| mærke | No Brand |
| model | PP047JC-02A |
| diagonal størrelse | 4.7 inch |
| type | LTPS TFT-LCD, CELL |
| pixel format | 750(RGB)×1334 325PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 58.5(H)×104.052(V) mm |
| omrids dim. | 61.08(H)×110.43(V) ×0.35(D) mm |
| luminans | 0 cd/m² |
| kontrastforhold | 1500:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| driftstilstand | Normally Black, Transmissive |
| pladetykkelse | 0.18+0.18 mm |
| transmission | 5.5% (Typ.)(with Polarizer) |
| støtte farve | 16.7M 67% NTSC |
| lyskilde | No B/L |
| vægt | - |
| designet til | Mobile Phone |
| billedhastighed | - |
| berøringspanel | Without |
| d-ic detalje | COG Built-in 1 source chips |
| DMF50081NB-FW | Kyocera | 4.7 | 320×240 |
| G321EV5R000 | SII | 4.7 | 320×240 |
| H466TAN01.0 | AUO | 4.7 | 720×1280 |
| KCG047QV1AA-A21 | Kyocera | 4.7 | 320×240 |
| LH467WX1-SD01 | LG Display | 4.7 | 768×1280 |
| LH470WX6-SJ11 | LG Display | 4.7 | 750×1334 |
| LM32K10 | SHARP | 4.7 | 320×240 |
| LQ047K3SX08 | SHARP | 4.7 | 720×1280 |
| LS047T1SC01K | SHARP | 4.7 | 1080×1920 |
| LS047T1SC02 | SHARP | 4.7 | 1080×1920 |
