| Varenummer | LS047T1SC01K |
| Mærke | SHARP |
| Størrelse | 4.7 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | LCM |
| Lysstyrke | 470 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LS047T1SC01K |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 4.7 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| aktivt område | 57.996×103.104 mm |
| omrids | 60.4×112.2×1.45 mm |
| overflade | |
| lysstyrke | 470 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193171% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 2 stringsWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 31 pins |
| indgangsspænding | 5.0/-5.0/1.8V (Typ.)(AVDD+/AVDD-/IOVDD) |
| Ansøgning | MPH |
| G321EV5R000 | SII | 4.7 | 320×240 |
| H466TAN01.1 | AUO | 4.7 | 720×1280 |
| H466TAN02.4 | AUO | 4.7 | 720×1280 |
| KCG047QV1AA-A21 | Kyocera | 4.7 | 320×240 |
| LH467WX1-SD01 | LG Display | 4.7 | 768×1280 |
| LM32010P | SHARP | 4.7 | 320×240 |
| LM32K10 | SHARP | 4.7 | 320×240 |
| LM32P101 | SHARP | 4.7 | 320×240 |
| LS047T1SC01K | SHARP | 4.7 | 1080×1920 |
| LS047T1SC02 | SHARP | 4.7 | 1080×1920 |
| AMS410GC01-0 | Samsung | 4.1 | 480×800 |
| BTL507212-W746L | BOE | 5.0 | 720×1280 |
| H320QN01 V2 | AUO | 3.2 | 320×480 |
| H497TLB01.4 | AUO | 5.0 | 720×1280 |
| LD043WV1-SP01 | LG Display | 4.3 | 480×854 |
| LH470WX6-SD02 | LG Display | 4.7 | 750×1334 |
| LS030B3UX01D | SHARP | 3.0 | 240×400 |
| PJ028MA-01A | Innolux | 2.8 | 240×320 |
| TD028STEB1 | TPO | 2.8 | 240×320 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
