| Varenummer | LQ047K3SX08 |
| Mærke | SHARP |
| Størrelse | 4.7 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LQ047K3SX08 |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 4.7 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| aktivt område | 58.104×103.296 mm |
| omrids | 61.912×114.38×2.3 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S1PWLEDWithout Driver |
| signal interface | MIPI (3 data lanes), 25 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(VDDIO/VCI) |
