| Varenummer | PW062XU8 |
| Mærke | E Ink |
| Størrelse | 6.2 |
| Ansøgning | CNS |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 400:1 |
| Farver | Full color |
| Baggrundsbelysning | WLED |
| Interface | Analog |
| panel mærke | PVI |
| panel model | PW062XU8 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.2 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 137.52×77.22 mm |
| omrids | 155.2×88.2 mm |
| overflade | Antiglare |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | Full color |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S8PWLEDWithout Driver |
| signal interface | TFT Specific Analog RGB, 26 pins |
| indgangsspænding | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| Ansøgning | CNS |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| L5F30947T00 | Epson | 6.5 | 800×480 |
| LA061WQ1-TD05 | LG Display | 6.1 | 480×272 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LB070WV8-SL01 | LG Display | 7.0 | 800×480 |
| LB080WV4-A1 | LG Display | 8.0 | 800×480 |
| LQ049B5DG02 | SHARP | 4.9 | 320×96 |
| LQ070Y5DG01 | SHARP | 7.0 | 800×480 |
| NL4827HC19-05A | NLT | 4.3 | 480×272 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
