| Varenummer | PW080XU4 |
| Mærke | E Ink |
| Størrelse | 8.0 |
| Ansøgning | CNS |
| Løsning | 480×220 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 400:1 |
| Farver | Full color |
| Baggrundsbelysning | WLED |
| Interface | Analog |
| panel mærke | PVI |
| panel model | PW080XU4 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 480(RGB)×220 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 180.72×94.27 mm |
| omrids | 193×108.3×7 mm |
| overflade | Antiglare |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | Full color |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S9PWLEDWithout Driver |
| signal interface | TFT Specific Analog RGB, 30 pins |
| indgangsspænding | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VCCG/AVDD/VGH/VEE) |
| Ansøgning | CNS |
| AT080TN64 | Innolux | 8.0 | 800×480 |
| C080VW02 V0 | AUO | 8.0 | 800×480 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| LM64C21P | SHARP | 8.0 | 640×480 |
| LQ080Y5CGQ1 | SHARP | 8.0 | 800×480 |
| LTA080B441A | TOSHIBA | 8.0 | 480×234 |
| PW080XU1 | E Ink | 8.0 | 480×220 |
| PW080XU4 | E Ink | 8.0 | 480×220 |
| C065GW01 V0 | AUO | 6.5 | 400×234 |
| C065VL01 V0 | AUO | 6.5 | 800×480 |
| C070FW02 V0 | AUO | 7.0 | 480×234 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| G150X1-L01 | Innolux | 15.0 | 1024×768 |
| LQ049B5DG04 | SHARP | 4.9 | 320×96 |
| M101GWT9 R3 | IVO | 10.1 | 1024×600 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| ZJ080NA-08A | Innolux | 8.0 | 1024×600 |
