| Varenummer | R300SFE-L02 |
| Mærke | Innolux |
| Størrelse | 30.0 |
| Ansøgning | MD |
| Løsning | 3280×2048 |
| Sammensætning | LCM |
| Lysstyrke | 800 |
| CR | 1000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | INNOLUX |
| panel model | R300SFE-L02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 30.0 inch |
| løsning | 3280(RGB)×2048 |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 645.5×403.05 mm |
| omrids | 678×448×30.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 800 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 1.07B (10-bit), CIE193169% |
| responstid | 15/15 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (8 ch, 10-bit) |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | MD |
