| Varenummer | RX840-C10 |
| Mærke | ROGIN |
| Størrelse | 84 |
| Ansøgning | PID |
| Løsning | 3840×2160 |
| Sammensætning | LCM |
| Lysstyrke | 1000 |
| CR | 1400:1 |
| Farver | 16.7M/1.06B |
| Baggrundsbelysning | WLED |
| Interface | V-by-One |
| panel mærke | ROGIN |
| panel model | RX840-C10 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 84 inch |
| løsning | 3840(RGB)×2160 , UHD |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 1860.48×1046.52 mm |
| omrids | 1904×1096×42.3 mm |
| overflade | Antiglare (Haze 10%), Hard coating (3H) |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 1400:1 (Typ.) |
| vise farver | 16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172% |
| responstid | 12 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz+120Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | V-by-One 16 lane, 97 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| BRS420H2 | 42 | 1920×1080 | |
| LD420WUN-SCA1 | LG Display | 42 | 1920×1080 |
| LD470EUD-SDA1 | LG Display | 47 | 1920×1080 |
| LD650EUF-FHB1 | LG Display | 65 | 1920×1080 |
| LTI220MT02 | Samsung | 22.0 | 1680×1050 |
| LTI430LA02 | Samsung | 43 | 1920×480 |
| LTI460HA01 | Samsung | 46 | 1920×1080 |
| LTI550HN04 | Samsung | 55 | 1920×1080 |
| P320HVN02.0 | AUO | 31.5 | 1920×1080 |
| RX430HD02-DC15 | ROGIN | 43 | 1920×1080 |
