| Varenummer | TCG070WVLQGPNN-AN40 |
| Mærke | Kyocera |
| Størrelse | 7.0 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 800×480 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 750:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| fabrikant | Kyocera |
| skærmstørrelse | 7.0 inch |
| pixel antal | 800(RGB)×480 (WVGA) 133PPI |
| aktivt område (mm) | 152.4 × 91.44 (H×V) |
| rammeareal (mm) | 154.4 × 93.4 (H×V) |
| luminans | 1000 cd/m² (Typ.) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| god udsigt kl | Symmetry |
| farvedybde | 262K/16.2M 50% NTSC |
| masse | 230g |
| opdateringshastighed | 60Hz |
| signaltype | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C |
| modelnavn | TCG070WVLQGPNN-AN40 |
| skærmtype | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| omrids (mm) | 169.8 × 109.7 × 9.7 (H×V×D) |
| behandling | Antiglare |
| kontrastforhold | 750 : 1 (Typ.) (TM) |
| respons | 18/12 (Typ.)(Tr/Td) ms |
| arbejdstilstand | AWV, Normally Black, Transmissive |
| baggrundsbelysning | WLED , 70K hours , With LED Driver |
| anvendes til | Industrial Outdoor High Brightness Automotive Display |
| berøringsskærm | Without |
