| Varenummer | G070Y3-T01 |
| Mærke | Innolux |
| Størrelse | 7.0 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 650:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | CMO |
| panel model | G070Y3-T01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 156×82.8 mm |
| omrids | 168×94×6.65 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 650:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 5/11 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S3PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 50 pins |
| indgangsspænding | 3.3/10.5/18/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | IA |
