| Varenummer | TD025THEEA |
| Mærke | TPO |
| Størrelse | 2.5 |
| Ansøgning | DSC |
| Løsning | 640×240 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | TPO |
| panel model | TD025THEEA |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 2.5 inch |
| løsning | 640×240 , HVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 50.28×37.8 mm |
| omrids | 61.7×44.5×2.98 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 13/22 (Typ.)(Tr/Td) |
| synsvinkel | 40/40/20/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2S1PWLEDWithout Driver |
| signal interface | Serial RGB (8-bit) + SPI, CCIR601, 40 pins |
| indgangsspænding | 3.0V (Typ.) |
| Ansøgning | DSC |
| 990000270 | TPO | 2.5 | 320×240 |
| LH250Q01-TH02 | LG Display | 2.5 | 320×240 |
| LMS250GF01 | Samsung | 2.5 | |
| LTV250QV-F0A | Samsung | 2.5 | 320×240 |
| TD025THEA3 | TPO | 2.5 | 320×240 |
| TD025THEB5 | TPO | 2.5 | 320×240 |
| TD025THED2 | TPO | 2.5 | 320×240 |
| TD025THEE6 | TPO | 2.5 | 640×240 |
| TD025THEEA | TPO | 2.5 | 640×240 |
| TD025THEG1 | TPO | 2.5 | 320×240 |
| A025DN01 V9 | AUO | 2.5 | 320×240 |
| A027DN03 V2 | AUO | 2.7 | 320×240 |
| A030DN01 VC | AUO | 3.0 | 320×240 |
| A035QN02 VE | AUO | 3.5 | 320×240 |
| ACX318ELN | SONY | 1.5 | 490×240(dot) |
| DLC0350CZG-T | Other | 3.5 | 320×240 |
| LMS350GF07-005 | Samsung | 3.5 | 320×240 |
| LQ035LC111 | Innolux | 3.5 | 320×240 |
| PD035OX4 | E Ink | 3.5 | 320×234 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
