| Varenummer | TD025THEG1 |
| Mærke | TPO |
| Størrelse | 2.5 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | TPO |
| panel model | TD025THEG1 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 2.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 49.946×37.56 mm |
| omrids | 56.2×47.8 mm |
| overflade | Antiglare, Hard coating |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 5/11 (Typ.)(Tr/Td) |
| synsvinkel | 40/40/20/50 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 2S1PWLED |
| signal interface | Serial RGB (8-bit) + SPI, CCIR601, 40 pins |
| indgangsspænding | 3.3V (Typ.)(VCC) |
| Ansøgning | DSC |
| A018AN03 V1 | AUO | 1.8 | 280×220 |
| A024CN02 VL | AUO | 2.4 | 480×234 |
| A025DL02 V5 | AUO | 2.5 | 320×240 |
| L3F04X-80300C | Epson | 0.48 | 1024×768 |
| LQ035NC111 | Innolux | 3.5 | 320×240 |
| LTV350QV-F09 | Samsung | 3.5 | 320×240 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| TD030WHEA1 | TPO | 3.0 | 320×240 |
| TM027CDH19 | Tianma | 2.7 | 320×240 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
