| Varenummer | TD025THED2 |
| Mærke | TPO |
| Størrelse | 2.5 |
| Ansøgning | MPH |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 350:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | TPO |
| panel model | TD025THED2 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 2.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 49.92×37.44 mm |
| omrids | 56.4×49.12×2.5 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193170% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 55/55/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 39 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(VDDI/VDD) |
| Ansøgning | MPH |
