| Varenummer | TD028STEB2 |
| Mærke | TPO |
| Størrelse | 2.8 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 150 |
| CR | 150:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | TPO |
| panel model | TD028STEB2 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 2.8 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 43.2×57.6 mm |
| omrids | 52.9×71.7 mm |
| overflade | |
| lysstyrke | 150 cd/m² (Typ.) |
| kontrastforhold | 150:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 40/45/60/35 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 4S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 61 pins |
| indgangsspænding | 2.8V (Typ.)(DVDD) |
| Ansøgning | MPH |
