| Varenummer | LD043WV1-SP01 |
| Mærke | LG Display |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 480×854 |
| Sammensætning | LCM |
| Lysstyrke | 440 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | LG Display |
| panel model | LD043WV1-SP01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×854 , FWVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 53.568×96.306 mm |
| omrids | 59.97×107.31 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 440 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 4S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| indgangsspænding | 3.0/1.8V (Typ.)(VIC/VDDI) |
| Ansøgning | MPH |
