| Varenummer | TD070WGCB1 |
| Mærke | TPO |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 854×480 |
| Sammensætning | LCM |
| Lysstyrke | 420 |
| CR | 150:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | Toppoly |
| panel model | TD070WGCB1 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 854(RGB)×480 , FWVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 155×87.12 mm |
| omrids | 166.4×106.3×8.9 mm |
| overflade | |
| lysstyrke | 420 cd/m² (Typ.) |
| kontrastforhold | 150:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 7/18 (Typ.)(Tr/Td) |
| synsvinkel | 75/75/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | CNS |
| BP070WS1-200 | BOE | 7.0 | 1024×600 |
| EJ070IA-04A | Innolux | 7.0 | 800×1280 |
| LB070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LB070WV7-TD01 | LG Display | 7.0 | 800×480 |
| LD070WX5-SM01 | LG Display | 7.0 | 900×1440 |
| TD070WGCB1 | TPO | 7.0 | 854×480 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
| TM070DDH08 | Tianma | 7.0 | 1024×600 |
| CLAA070NJ01CW | CPT | 7.0 | 1024×600 |
| DLC1040ABG-T-2 | Other | 10.4 | 800×600 |
| FG0700G3DSSWBGL4 | Data Image | 7.0 | 800×480 |
| L5F30614T65 | SANYO | 8.0 | 800×480 |
| LQ050T5DW02 | SHARP | 5.0 | 400×240 |
| LQ065T9BR54U | SHARP | 6.5 | 400×240 |
| LQ070T5AR01 | SHARP | 7.0 | 480×234 |
| LQ070T5DR02 | SHARP | 7.0 | 480×240 |
| LQ080T5GG01B | SHARP | 8.0 | 480×234 |
| PW070XUA | E Ink | 7.0 | 480×234 |
