| Varenummer | TD070WGCB2 |
| Mærke | TPO |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 854×480 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 450:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | Toppoly |
| panel model | TD070WGCB2 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 854(RGB)×480 , FWVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 155×87.12 mm |
| omrids | 166.4×106.3×8.9 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 450:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 7/18 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | CNS |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| A070VTN03.0 | AUO | 7.0 | 800×480 |
| AT070TN90 V.1 | Innolux | 7.0 | 800×480 |
| CLAA070NJ01CW | CPT | 7.0 | 1024×600 |
| EE070NA-01D | Innolux | 7.0 | 1024×600 |
| LMS700KF21 | Samsung | 7.0 | 800×480 |
| LQ070S1DW01 | SHARP | 7.0 | 600×800 |
| LQ070Y5DG01 | SHARP | 7.0 | 800×480 |
| TD070WGCB1 | TPO | 7.0 | 854×480 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
| 70WVW4A | SII | 7.0 | 800×480 |
| A070VW05 V1 | AUO | 7.0 | 800×480 |
| AT080TN03 V.2 | Innolux | 8.0 | 800×480 |
| C070FW02 V2 | AUO | 7.0 | 480×234 |
| LQ042T5DZ01A | SHARP | 4.2 | 480×272 |
| LQ050A5BS01 | SHARP | 5.0 | 320×234 |
| LQ065T9DZ03 | SHARP | 6.5 | 400×240 |
| LQ065Y5DZ01 | SHARP | 6.5 | 800×480 |
| LQ070T5DG30 | SHARP | 7.0 | |
| TFD65W46 | TOSHIBA | 6.5 | 480×234 |
