| Varenummer | LQ050T5DW02 |
| Mærke | SHARP |
| Størrelse | 5.0 |
| Ansøgning | CNS |
| Løsning | 400×240 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 1200:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ050T5DW02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 400×240(RGB) , WQVGA |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 108×64.8 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/10 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/45/45 (Typ.)(CR≥200)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
| LQ050A3AD01 | SHARP | 5.0 | 320×234 |
| LQ050A5BS01 | SHARP | 5.0 | 320×234 |
| LQ050A5BS02 | SHARP | 5.0 | 320×234 |
| LQ050T1SX02 | SHARP | 5.0 | 1080×1920 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LQ050T3GG01 | SHARP | 5.0 | 400×234 |
| LQ050T5DG01 | SHARP | 5.0 | 400×240 |
| LQ050T5DG02 | SHARP | 5.0 | 400×240 |
| LQ050T5DW02 | SHARP | 5.0 | 400×240 |
| LQ050W1LA0A | SHARP | 5.0 | 1024×600 |
| AT062TN12 | Innolux | 6.2 | |
| CLAA070LFB1 CW | CPT | 7.0 | 800×480 |
| CLAA070NJ01CW | CPT | 7.0 | 1024×600 |
| HSD050I9W1-A00 | HannStar | 5.0 | 480×272 |
| LB043WQ4-TD01 | LG Display | 4.3 | 480×272 |
| LQ080T5GG01B | SHARP | 8.0 | 480×234 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224AC35-06 | NLT | 5.5 | 320×240 |
| PM065WX3 | E Ink | 6.5 | 800×480 |
| PM070WT2 | E Ink | 7.0 | 800×480 |
