| Varenummer | TL055BDXP03 |
| Mærke | TIANMA |
| Størrelse | 5.5 |
| Ansøgning | Mobile Phone |
| Løsning | 1440×2560 |
| Sammensætning | LCM , LTPS TFT-LCD |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 5S3P |
| Interface | MIPI |
| fabrikant | TIANMA |
| skærmstørrelse | 5.5 inch |
| pixel antal | 1440(RGB)×2560 (Quad-HD) 537PPI |
| aktivt område (mm) | 68.04 × 120.96 (H×V) |
| luminans | - |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| god udsigt kl | Symmetry |
| farvedybde | 16.7M 70% NTSC |
| masse | TBD |
| opdateringshastighed | 70Hz |
| signaltype | MIPI (2 ch, 4 data lanes) , 50 pins Connector |
| spændingsforsyning | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| max. vurderinger | Storage Temp.: -30 ~ 70 °C Operating Temp.: -30 ~ 60 °C |
| modelnavn | TL055BDXP03 |
| skærmtype | LCM , LTPS TFT-LCD |
| arrangement | RGB Vertical Stripe |
| omrids (mm) | 70.94 × 128.29 × 1.46 (H×V×D) |
| kontrastforhold | 800 : 1 (Typ.) (TM) |
| respons | 8 (Typ.)(Tr+Td) ms |
| arbejdstilstand | SFT, Normally Black, Transmissive |
| baggrundsbelysning | 5S3P WLED |
| anvendes til | Mobile Phone |
| berøringsskærm | Without |
