| Varenummer | LS055T1SX01 |
| Mærke | SHARP |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LS055T1SX01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 5.5 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 69.012×122.688 mm |
| omrids | 71.72×130.4×1.81 mm |
| overflade | Clear |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 30 pins |
| indgangsspænding | 1.8/5.6/-5.4V (Typ.)(VDDIO/VSP/VSN) |
| Ansøgning | MPH |
| AMS326PM01 | Samsung | 3.3 | 854×480 |
| AMS395GB01 | Samsung | 4.0 | 360×640 |
| BTL454885-W698L | BOE | 4.5 | 480×854 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| H345VW01 V0 | AUO | 3.5 | 480×800 |
| HVA37WV1-M02 | HYDIS | 3.7 | 480×800 |
| LH550WF4-SJ11 | LG Display | 5.5 | 1080×1920 |
| LQ043Y1DX02 | SHARP | 4.3 | 480×800 |
| MC15G30B | Other | 1.5 | 128×128 |
| TD025THED2 | TPO | 2.5 | 320×240 |
