| Varenummer | TM070RDHG12 |
| Mærke | TIANMA |
| Størrelse | 7.0 |
| Ansøgning | Portable DVD Player |
| Løsning | 800×480 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 500:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | Parallel |
| mærke | TIANMA |
| model | TM070RDHG12 |
| diagonal størrelse | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×480 [WVGA] 134PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 154.08(H)×85.92(V) mm |
| omrids dim. | 164.9(H)×100(V) ×6(D) mm |
| bezel område | 157.08(H)×89.39(V) mm |
| behandling | Antiglare |
| luminans | 350 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) (TM) |
| visningsretning | 12 o'clock |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/60/70 (Typ.)(CR≥10) |
| driftstilstand | TN, Normally White, Transmissive |
| støtte farve | 262K/16.7M 50% NTSC |
| lyskilde | WLED [3S7P] , 20K hours , W/O Driver |
| vægt | 165g (Typ.) |
| designet til | Portable DVD Player Digital Photo Frame |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | Parallel RGB (1 ch, 6/8-bit) , 60 pins FPC |
| Strømforsyning | 3.3/10.6/10.6/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| miljø | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
