| Varenummer | TM070WA-22L06 |
| Mærke | SANYO |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 100:1 |
| Farver | |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | TORISAN |
| panel model | TM070WA-22L06 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 154.08×87.05 mm |
| omrids | 167×102 mm |
| overflade | Antiglare |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Min.) |
| vise farver | |
| responstid | 30/20 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/30/40 (Max.)(CR≥5)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFL |
| signal interface | TFT Specific Analog RGB, 24 pins |
| indgangsspænding | 5.3/15.0/-14V (Typ.)(VSH/VGH/VGL) |
| Ansøgning | CNS |
