| Varenummer | TM084SDHG03 |
| Mærke | Tianma |
| Størrelse | 8.4 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 500:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | TIANMA |
| panel model | TM084SDHG03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.4 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 170.4×127.8 mm |
| omrids | 203×142.5×5.9 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S3PWLEDEmbedded (LED Driver) |
| signal interface | Parallel RGB (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084VD02 | Mitsubishi | 8.4 | 640×480 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| LQ9D03B | SHARP | 8.4 | 640×480 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| TM084SBHG04 | Tianma | 8.4 | 800×600 |
| TM084SDHG01 | Tianma | 8.4 | 800×600 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
| TM084SDHG50 | Tianma | 8.4 | 800×600 |
| AA150XN07 | Mitsubishi | 15.0 | 1024×768 |
| AM-800600M3TNQW-01H-F | AMPIRE | 8.4 | 800×600 |
| HGS128647-Y-EH-LV | Other | 1.54 | 128×64 |
| KCL6448HSTT-X12 | Kyocera | 9.4 | 640×480 |
| KS3224ASTT-FW-X20 | Kyocera | 5.7 | 320×240 |
| LC064N1 | LG Display | 6.4 | 640×480 |
| LQ10D421 | SHARP | 10.4 | 640×480 |
| LQ121S1DG21A | SHARP | 12.1 | 800×600 |
| LTM12C275A | TOSHIBA | 12.1 | 800×600 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
