| Varenummer | TM12864G3CCWGWA-1 |
| Mærke | Tianma |
| Størrelse | 2.4 |
| Ansøgning | IA |
| Løsning | 128×64 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | Monochrome |
| Baggrundsbelysning | WLED |
| Interface | SPI |
| panel mærke | TIANMA |
| panel model | TM12864G3CCWGWA-1 |
| paneltype | FSTN-LCD , LCM |
| panelstørrelse | 2.4 inch |
| løsning | 128×64 |
| visningstilstand | STN, Black/White (Positive), Transflective |
| aktivt område | 55×27.48 mm |
| omrids | 70×43×9 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 3:1 (Min.)(Reflective) |
| vise farver | Monochrome |
| responstid | 250/200 (Max.)(Tr/Td) |
| synsvinkel | |
| lampe type | 1S4PWLED |
| signal interface | SPI, 20 pins |
| indgangsspænding | 3.0V (Typ.) |
| Ansøgning | IA |
