| Varenummer | TPF0702001N |
| Mærke | JDI |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 1200×1920 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | MIPI |
| panel mærke | JDI |
| panel model | TPF0702001N |
| paneltype | LTPS TFT-LCD , CELL |
| panelstørrelse | 7.0 inch |
| løsning | 1200(RGB)×1920 , WUXGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 94.5×151.2 mm |
| omrids | 97.3×159.4 mm |
| overflade | Hard coating |
| transmissivitet | 5.2% (Typ.)(with Polarizer) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | MIPI (4 data lanes), 40 pins |
| indgangsspænding | 1.8/5.5/-5.5 (Typ.)(IOVCC/VSP/VSN) |
| Ansøgning | PAD |
| B079XAN01.0 | AUO | 7.9 | 768×1024 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| HX104X01-210 | HYDIS | 10.4 | 1024×768 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| LD070WX5-SM01 | LG Display | 7.0 | 900×1440 |
| LQ104X2LX05A | SHARP | 10.4 | 1024×768 |
| LTL089CL02-002 | Samsung | 8.9 | 1920×1200 |
| LTL101AL06-002 | Samsung | 10.1 | 1280×800 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| P080KDZ-3Z1 | Innolux | 8.0 | 1200×1920 |
