| Varenummer | P080KDZ-3Z1 |
| Mærke | Innolux |
| Størrelse | 8.0 |
| Ansøgning | PAD |
| Løsning | 1200×1920 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | MIPI |
| panel mærke | INNOLUX |
| panel model | P080KDZ-3Z1 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 8.0 inch |
| løsning | 1200(RGB)×1920 , WUXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 107.64×172.224 mm |
| omrids | 112.64×181.8 mm |
| overflade | Hard coating |
| glas dybde | 0.40+0.40 mm |
| transmissivitet | 3.85% (Typ.)(with Polarizer) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193160% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | MIPI (4 data lanes), 40 pins |
| indgangsspænding | 3.3/10.0/21.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| Ansøgning | PAD |
