| Varenummer | TT101WSQ-N10 |
| Mærke | BOE |
| Størrelse | 10.1 |
| Ansøgning | NBPC |
| Løsning | 1024×600 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | BOE |
| panel model | TT101WSQ-N10 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 10.1 inch |
| løsning | 1024(RGB)×600 , WSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 222.72×125.28 mm |
| omrids | 230.4×134.2 mm |
| overflade | |
| transmissivitet | 6.17% (Typ.)(with Polarizer) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193155% |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/55/70 (Typ.)(CR≥10)(L/R/U/D) |
| Ansøgning | NBPC |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| B101EW02 V1 | AUO | 10.1 | 1280×720 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| F101NWN7-0 | IVO | 10.1 | 1920×1200 |
| HJ101IA-01F | Innolux | 10.1 | 1280×800 |
| HJ101NA-02A | Innolux | 10.1 | 1280×800 |
| LP101WSA-TLA1 | LG Display | 10.1 | 1024×600 |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| LTL101AL02-T01 | Samsung | 10.1 | 1280×800 |
| TT101WSQ-N10 | BOE | 10.1 | 1024×600 |
| B154EW01 VC | AUO | 15.4 | 1280×800 |
| B154PW01 V0 | AUO | 15.4 | 1440×900 |
| LQ084S1DH10 | SHARP | 8.4 | 800×600 |
| LTN141X4-156 | Samsung | 14.1 | 1024×768 |
| LTN150PF-L04 | Samsung | 15.0 | 1400×1050 |
| LTN154P3-L05 | Samsung | 15.4 | 1680×1050 |
| N140B6-L02 | Innolux | 14.0 | 1366×768 |
| N154I4-L04 | Innolux | 15.4 | 1280×800 |
| N156BGE-E41 | Innolux | 15.6 | 1366×768 |
| NT156WHM-N12 | BOE | 15.6 | 1366×768 |
