| Varenummer | LTL101AL02-T01 |
| Mærke | Samsung |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTL101AL02-T01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | PLS, Normally Black, Transmissive |
| aktivt område | 216.96×135.6 mm |
| omrids | 228.06×148.05×4.79 mm |
| overflade | Hard coating (2H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S4PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| LTL101AL01-W01 | Samsung | 10.1 | 1280×800 |
| LTL101AL02-T01 | Samsung | 10.1 | 1280×800 |
| LTL101AL03-W01 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-002 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-003 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-104 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-801 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-W02 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-W14 | Samsung | 10.1 | 1280×800 |
| CLAA101FP05 | CPT | 10.1 | 1920×1200 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| HE070IA-04F | Innolux | 7.0 | 800×1280 |
| LP125WH2-SLT1 | LG Display | 12.5 | 1366×768 |
| LTL097QL01-A01 | Samsung | 9.7 | 2048×1536 |
| LTL101DL03-T01 | Samsung | 10.1 | 2560×1600 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| VVX07F023B00 | Panasonic | 7.0 | 1200×1920 |
| VVX07H005A00 | Panasonic | 7.0 | 800×1280 |
| VVX10F034N00 | Panasonic | 10.1 | 1920×1200 |
