| Varenummer | TX18D211VM0BAA |
| Mærke | KOE |
| Størrelse | 7.0 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 800×480 |
| Sammensætning | LTPS TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | KOE |
| panel model | TX18D211VM0BAA |
| panelstørrelse | 7.0" |
| paneltype | LTPS TFT-LCD, LCM |
| løsning | 800(RGB)×480, WVGA, 133PPI |
| pixel format | RGB Vertical Stripe |
| udstillingsområde | 152.4(W)×91.44(H) mm |
| bezel åbning | 156.2(W)×94.5(H) mm |
| konturstørrelse | 167.7(W)×109.5(H) ×20.3(D) mm |
| overflade | - |
| lysstyrke | 1200 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| visningstilstand | IPS, Normally Black, Transmissive |
| bedste udsigt på | Symmetry |
| responstid | 30 (Typ.)(Tr+Td) |
| vise farver | 262K 73% NTSC |
| lampe type | WLED , 50K hours , With LED Driver |
| frekvens | 60Hz |
| berøringsskærm | Without |
| panelvægt | 219g (Typ.) |
| Ansøgning | Industrial Outdoor High Brightness Automotive Display |
| signal interface | LVDS (1 ch, 6-bit) , 20 pins Connector |
| indgangsspænding | 3.3V (Typ.) |
| miljø | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| CLAA070LF06CW | CPT | 7.0 | 800×480 |
| LA070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LMS700KF01-001 | Samsung | 7.0 | 800×480 |
| LQ070T5BG01 | SHARP | 7.0 | 480×234 |
| LQ070Y3LW01 | SHARP | 7.0 | 800×480 |
| LR700BA9005 | Innolux | 7.0 | 480×234 |
| LW700AT9008 | Innolux | 7.0 | 800×480 |
| TX18D37VM0ARA | KOE | 7.0 | 800×480 |
