| Varenummer | RGS10096064FR020 |
| Mærke | RiTdisplay |
| Størrelse | 0.95 |
| Ansøgning | IA |
| Løsning | 96×64 |
| Sammensætning | OLED |
| Lysstyrke | 100 |
| CR | 2000:1 |
| Farver | 65K |
| Baggrundsbelysning | self |
| Interface | CPU/SPI |
| panel mærke | RiTdisplay |
| panel model | RGS10096064FR020 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 0.95 inch |
| løsning | 96(RGB)×64 |
| aktivt område | 20.135×13.42 mm |
| omrids | 24.2×20.9×1.51 mm |
| overflade | Antiglare |
| lysstyrke | 100 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Typ.) |
| vise farver | 65K |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 85Hz |
| driver ic | COG Built-in SEPS114A |
| signal interface | 8-bit 6800/8080 parallel, 4-wire SPI, 34 pins |
| indgangsspænding | 13.0V (Typ.)(VCC) |
| Ansøgning | IA |
