| Varenummer | V260B3-L01 |
| Mærke | Innolux |
| Størrelse | 26.0 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | V260B3-L01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 26.0 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 575.769×323.712 mm |
| omrids | 626×373 mm |
| overflade | Antiglare (Haze 11%), Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 8.5 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| V260B1-L01 | Innolux | 26.0 | 1366×768 |
| V260B1-L02 | Innolux | 26.0 | 1366×768 |
| V260B1-L03 | Innolux | 26.0 | 1366×768 |
| V260B1-L11 | Innolux | 26.0 | 1366×768 |
| V260B2-L01 | Innolux | 26.0 | 1366×768 |
| V260B2-L04 | Innolux | 26.0 | 1366×768 |
| V260B3-L01 | Innolux | 26.0 | 1366×768 |
| V260B3-L07 | Innolux | 26.0 | 1366×768 |
| V260B3-LE1 | Innolux | 26.0 | 1366×768 |
| V260B3-LE2 | Innolux | 26.0 | 1366×768 |
| AX080E002B | KOE | 31.5 | 1366×768 |
| LC320EUD-SEM1 | LG Display | 31.5 | 1920×1080 |
| LC370EUN-SDV2 | LG Display | 37 | 1920×1080 |
| LC420EUF-PFF1 | LG Display | 42 | 1920×1080 |
| LC420EUS-SCA2 | LG Display | 42 | 1920×1080 |
| LTA400HM07 | Samsung | 40 | 1920×1080 |
| LTY460HB01 | Samsung | 46 | 1920×1080 |
| T390HVF01.0 | AUO | 39 | 1920×1080 |
| T645HF02 V1 | AUO | 65 | 1920×1080 |
| V400DJ1-QS5 | Innolux | 40 | 3840×2160 |
