| Varenummer | VVX11F009G00 |
| Mærke | Panasonic |
| Størrelse | 11.6 |
| Ansøgning | PAD |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 570 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | Panasonic |
| panel model | VVX11F009G00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 11.6 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | IPS-Pro, Normally Black, Transmissive |
| aktivt område | 256.896×144.504 mm |
| omrids | 268.896×166.564 mm |
| overflade | Antiglare |
| lysstyrke | 570 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 26 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S5PWLEDEmbedded (LED Driver) |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW4A | AUO | 11.6 | 1366×768 |
| B116XW05 V004 | AUO | 11.6 | 1366×768 |
| LP116WH6-SPA2 | LG Display | 11.6 | 1366×768 |
| LTN116AT01-401 | Samsung | 11.6 | 1366×768 |
| N116BGE-LB1 | Innolux | 11.6 | 1366×768 |
| N116HSE-EJ1 | Innolux | 11.6 | 1920×1080 |
| NT116WHM-N31 | BOE | 11.6 | 1366×768 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
| VVX11F019G00 | Panasonic | 11.6 | 1920×1080 |
| B080UAN01.2 | AUO | 8.0 | 1200×1920 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101EVT05.0 | AUO | 10.1 | 1280×800 |
| BP070WSA-400 | BOE | 7.0 | 1024×600 |
| LD089WX1-SL03 | LG Display | 8.9 | 1280×768 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| LP125WH2-SPM2 | LG Display | 12.5 | 1366×768 |
| LQ097L1JY02Z | SHARP | 9.7 | 2048×1536 |
| TV096WXM-NS0 | BOE | 9.6 | 800×1280 |
| VVX07H005A00 | Panasonic | 7.0 | 800×1280 |
