| Varenummer | WEA012864DWPP3N00001 |
| Mærke | Winstar |
| Størrelse | 0.96 |
| Ansøgning | Instruments & Me |
| Løsning | 128×64 |
| Sammensætning | PM-OLED, OLED |
| Lysstyrke | |
| CR | |
| Farver | Mono(White) |
| Baggrundsbelysning | self |
| Interface | 4-wire |
| mærke | Winstar |
| model | WEA012864DWPP3N00001 |
| diagonal størrelse | 0.96 inch |
| type | PM-OLED, OLED |
| pixel format | 128×64 149PPI |
| konfiguration | Rectangle |
| aktivt område | 21.74(H)×10.86(V) mm |
| omrids dim. | 38(H)×28.5(V) ×4.37(D) mm |
| bezel område | 23.94(H)×12.06(V) mm |
| behandling | - |
| visningsretning | Symmetry |
| responstid | - |
| synsvinkel | - |
| driftstilstand | - |
| støtte farve | Mono(White) |
| lyskilde | self |
| vægt | - |
| designet til | Instruments & Meters |
| billedhastighed | - |
| berøringspanel | Without |
| d-ic detalje | COG Built-in SSD1306BZ |
| interface type | 4-wire SPI, I²C , 8 pins PIN |
| Strømforsyning | 3.3/5.0/7.5V (Typ.) |
| miljø | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
