| Varenummer | WEO009664AL |
| Mærke | Winstar |
| Størrelse | 0.95 |
| Ansøgning | Wearable MP3 PMP |
| Løsning | 96×64 |
| Sammensætning | PM-OLED, OLED |
| Lysstyrke | |
| CR | |
| Farver | Mono(Yellow) |
| Baggrundsbelysning | self |
| Interface | 8-bit |
| mærke | Winstar |
| model | WEO009664AL |
| diagonal størrelse | 0.95 inch |
| type | PM-OLED, OLED |
| pixel format | 96×64 121PPI |
| konfiguration | Rectangle |
| aktivt område | 19.946(H)×13.418(V) mm |
| omrids dim. | 24.9(H)×22.95(V) ×1.95(D) mm |
| bezel område | 21.953(H)×15.424(V) mm |
| behandling | - |
| visningsretning | Symmetry |
| responstid | - |
| synsvinkel | - |
| driftstilstand | - |
| støtte farve | Mono(Yellow) |
| lyskilde | self |
| vægt | - |
| designet til | Wearable MP3 PMP |
| billedhastighed | - |
| berøringspanel | Without |
| d-ic detalje | COG Built-in SSD1305Z |
| interface type | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 25 pins FPC |
| Strømforsyning | 3.0V (Typ.) |
| miljø | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
| L3C09X-82G00 | Epson | 0.95 | 1280×800 |
| OEL9M1010-B-E | Other | 0.95 | 96×64 |
| OEL9M1010-G-E | Other | 0.95 | 96×64 |
| OEL9M1010-R-E | Other | 0.95 | 96×64 |
| OEL9M1010-W-E | Other | 0.95 | 96×64 |
| OEL9M1010-Y-E | Other | 0.95 | 96×64 |
| RGS10096064FR020 | RiTdisplay | 0.95 | 96×64 |
| RGS10096064YR000 | RiTdisplay | 0.95 | 96×64 |
| UG-9664HDDAG01 | WiseChip | 0.95 | 96×64 |
| UG-9664HLBAG01 | WiseChip | 0.95 | 96×64 |
