| Varenummer | A061FW01 V0 |
| Mærke | AUO |
| Størrelse | 6.1 |
| Ansøgning | CNS |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 500:1 |
| Farver | Full color |
| Baggrundsbelysning | WLED |
| Interface | Analog |
| panel mærke | AUO |
| panel model | A061FW01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.1 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 136.08×71.955 mm |
| omrids | 149×82.9 mm |
| overflade | Antiglare (Haze 25%) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | Full color , CIE193150% |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 6S3PWLEDWithout Driver |
| signal interface | TFT Specific Analog RGB, 30 pins |
| indgangsspænding | 3.3/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
