| Varenummer | A070FW03 V3 |
| Mærke | AUO |
| Størrelse | 7.0 |
| Ansøgning | VDP |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 400:1 |
| Farver | |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | AUO |
| panel model | A070FW03 V3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 154.08×86.58 mm |
| omrids | 164.9×100 mm |
| overflade | Antiglare (Haze 5.5%) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | |
| responstid | 12/18 (Typ.)(Tr/Td) |
| synsvinkel | 55/55/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 26 pins |
| indgangsspænding | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | VDP |
| A070FW01 | AUO | 7.0 | 480×234 |
| A070FW03 V1 | AUO | 7.0 | 480×234 |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| A070FW03 V4 | AUO | 7.0 | 480×234 |
| A070FW03 V6 | AUO | 7.0 | 480×234 |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| A070FW03 V8 | AUO | 7.0 | 480×234 |
| A070FW03 VB | AUO | 7.0 | 480×234 |
| A070FW03 VD | AUO | 7.0 | 480×234 |
| A070FW05 V1 | AUO | 7.0 | 480×234 |
| A056DN01 | AUO | 5.6 | 320×234 |
| A070FW03 VD | AUO | 7.0 | 480×234 |
| AT050TN22 V.1 | Innolux | 5.0 | 640×480 |
| AT056TN03 | Innolux | 5.6 | 320×234 |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| CLAA070WA01 | CPT | 7.0 | 480×234 |
| LB065WQ3-TD02 | LG Display | 6.5 | 400×240 |
| LQ050A3AD01 | SHARP | 5.0 | 320×234 |
| PA064DS1 | E Ink | 6.4 | 320×234 |
| TM056KDH01 | Tianma | 5.6 | 320×234 |
