| Varenummer | A080SN03 V0 |
| Mærke | AUO |
| Størrelse | 8.0 |
| Ansøgning | DPF |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 500:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A080SN03 V0 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 800×600(RGB) , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 162×121.5 mm |
| omrids | 183×141×5.2 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193150% |
| responstid | 12/18 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S6PWLEDWithout Driver |
| signal interface | TTL (1 ch, 8-bit) + SPI, 60 pins |
| indgangsspænding | 3.3/5/-5/14/-14V (Typ.)(VDDIO/VDPA/VDNA/VGH/VGL) |
| Ansøgning | DPF |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| A080SN01 V5 | AUO | 8.0 | 800×600 |
| A080SN01 V8 | AUO | 8.0 | 800×600 |
| A080SN02 V0 | AUO | 8.0 | 800×600 |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| A080SN03 V2 | AUO | 8.0 | 800×600 |
| A080SN03 V3 | AUO | 8.0 | 800×600 |
| AV080WSM-NW0 | BOE | 8.0 | 1024×600 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| HJ080IA-01B | Innolux | 8.0 | 1024×768 |
| A070FW03 VB | AUO | 7.0 | 480×234 |
| AT070TN90 | Innolux | 7.0 | 800×480 |
| AT080TN03 V.7 | Innolux | 8.0 | 800×480 |
| HSD070IDW1-A00 | HannStar | 7.0 | 800×480 |
| HSD080IDW1-A00 | HannStar | 8.0 | 800×480 |
| HSD101PFW3-D00 | HannStar | 10.1 | 1024×600 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| LB104S02-TD01 | LG Display | 10.4 | 800×600 |
| LW700AT9901 | Innolux | 7.0 | 800×480 |
| PW070XU3 | E Ink | 7.0 | 480×234 |
