| Varenummer | PW070XU3 |
| Mærke | E Ink |
| Størrelse | 7.0 |
| Ansøgning | DPF |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 350:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | PVI |
| panel model | PW070XU3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 154.08×86.58 mm |
| omrids | 166×100×7.5 mm |
| overflade | Antiglare, Hard coating |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | Full color |
| responstid | 10/20 (Typ.)(Tr/Td) |
| synsvinkel | 55/55/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 26 pins |
| indgangsspænding | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC1/VCC2/AVDD/VGH/VGL) |
| Ansøgning | DPF |
