| Varenummer | A080SN03 V3 |
| Mærke | AUO |
| Størrelse | 8.0 |
| Ansøgning | DPF |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 210 |
| CR | 500:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A080SN03 V3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 800×600(RGB) , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 162×121.5 mm |
| omrids | 183×141×5 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 210 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193150% |
| responstid | 12/18 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S6PWLEDWithout Driver |
| signal interface | TTL (1 ch, 8-bit) + SPI, 60 pins |
| indgangsspænding | 3.3/5/-5/14/-14V (Typ.)(VDDIO/VDPA/VDNA/VGH/VGL) |
| Ansøgning | DPF |
